CDH6000 – CALIBRATOR FOR H6000 LEAK DETECTOR
The CDH6000 is a gas H2N2 (5% hydrogen) supply that checks the calibration of the H6000.
It can be used with one or several calibrated leaks.
CDH6000 : FEATURES
• The CDH6000 must be fitted with a calibrated leak to deliver a known quantity of gas H2 N2 (5% hydrogen) at a given pressure.
• If the pressure displayed on the gauge of CDH6000 does not exceed 1 bar, change the cartridge (maximum pressure: 4 bar)
• To purchase cartridges filled with gas H2 N2 (5% hydrogen) contact ATEQ.
![CDH600-2020-2](https://www.ateq.es/wp-content/uploads/2020/12/CDH600-2020-2.jpg)
![H6000-BIAIS-600×600](https://www.ateq.es/wp-content/uploads/2021/03/H6000-BIAIS-600x600-1.jpg)
Tips : When the operator has finished using the calibrator CDH6000 disconnect the calibrated leak and store in its case and avoid the excessive pollution of the test area.
CDH6000 : OPERATIONS
![Button-ateq-cd-1](https://www.ateq.es/wp-content/uploads/2020/12/Button-ateq-cd-1.jpg)
![cdh-tu-1](https://www.ateq.es/wp-content/uploads/2020/12/cdh-tu-1.jpg)
CARTRIDGE EXTENSION
![cdh-tu23](https://www.ateq.es/wp-content/uploads/2020/12/cdh-tu23.jpg)
CARTRIDGE EXTRACTED
![Button-ateq-cd-3](https://www.ateq.es/wp-content/uploads/2020/12/Button-ateq-cd-3.jpg)
![cdh-tu-3](https://www.ateq.es/wp-content/uploads/2020/12/cdh-tu-3.jpg)
To change the cartridge, remove it by pressing the button on the connector. Then, insert a new cartridge by sliding it down until it «clicks» into place
![Button-ateq-cd-5](https://www.ateq.es/wp-content/uploads/2020/12/Button-ateq-cd-5.jpg)
![cdh-tu-4](https://www.ateq.es/wp-content/uploads/2020/12/cdh-tu-4.jpg)
Install the calibrated leak on the input connector of the CDH6000
![Button-ateq-cd-4](https://www.ateq.es/wp-content/uploads/2020/12/Button-ateq-cd-4.jpg)
![cdh-tu-5](https://www.ateq.es/wp-content/uploads/2020/12/cdh-tu-5.jpg)
CDH6000 : FACTSHEETS
Detailed information about the CDH6000 including features, specifications, etc.
